GL.iNet GL-X1200 3G 4G OpenWRT router industrial grade with RS232

FOB Reference Price:Get Latest Price
$170.00 - $270.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
GL-X1200
Lead Time:
Quantity(Sets) 1 - 100 >100
Est. Time(days) 10 Negotiable
Report Suspicious Activity
Overview
Quick Details
Max. LAN Data Rate:
867Mbps
With Modem Function:
No
Standards And Protocols:
Wi-Fi 802.11ac, Wi-Fi 802.11b, Wi-Fi 802.11g, Wi-Fi 802.11n
Wi-Fi Supported Frequency:
2.4G & 5G
Wi-Fi Transmission Standard:
802.11ac
Wired Transfer Rate:
10/100/1000Mbps
2.4G Wi-Fi Transmission Rate:
300 Mbps
Products Status:
Stock
Type:
Wireless
Application:
Enterprise
Function:
Firewall, QoS, VPN, RS485
LAN Ports:
4
WAN Ports:
1
Certification:
CE/FCC
Brand Name:
GL.iNet
Place of Origin:
Guangdong, China
CPU:
QCA9563 @775MHz SoC
Memory/Storage:
DDR2 128MB/Flash 16MB
Protocol:
802.11 a/b/g/n/ac
Wireless Speed:
5.8Ghz: 867Mbps; 2.4Ghz:300Mbps
Ethernet port:
5x Gigabit RJ45 ports
Antenna:
2x WiFi Antennas; 4x LTE antennas (Optional)
RS485/RS232 protocol:
Optional
GPS:
GPS chip included
Working temeprature:
-20~70°C(-4~158°F)
TX power:
<23dBm
Supply Ability
Supply Ability:
60000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Carton package
With power adapter, LTE antennas, GPS antenna, WIFI antennas.
Port
Shenzhen;HongKong
Lead Time :
Quantity(Sets) 1 - 100 >100
Est. Time(days) 10 To be negotiated
Product Description

GL-X1200 is an industrial  4G LTE router developed by GL-iNet which supports IEEE802.11b/g/n and IEEE802.11ac standards and it provides up to 1167Mbps Wi-Fi speed with 2.4G/5G dual frequency.


GL-X1200 supports 2 built-in industrial grade 3G/4G modules. It supports LTE CAT4 (Downlink 150Mbps, Uplink 50Mbps) or LTE CAT6 (Downlink 300Mbps, Uplink 150Mbps).

It has four external high gain antennas, 2x 4G LTE antennas, 2x Wi-Fi antennas. (2 extra antennas are required when use CAT 6 LTE modem.)

A GPS module is optional, an extra external antenna is required when use GPS module.

A built-in watchdog timer is to ensure stable operation of GL-X1200.


GL-X1200 has USB2.0 port and MicroSD card slot which providing the convenience of use external USB devices and extend storage.

GL-X1200 is based on OpenWrt opensource platform which brings routing function and wireless access point together and can be flexible expanded.

Product Features

Powered by Qualcomm chipset. It has high performance and reliability, low failure rate.
Optional Internal LTE CAT4 or CAT6 module. Optional e-SIM card.
802.11n 2x2 MIMO and 802.11ac, maximum 1167Mps Wi-Fi speed.
Support internal GPS/BDS module.
Watchdog timer is included.
Support RS232 or RS485 serial port (RJ45 port type).
Dual 4G LTE works concurrent, it supports bandwidth consolidation and load balancing.
Support PPPoE, dynamic IP and static IP.
Support AP and repeater functions.
Support multiple security mechanisms, support mainstream encryption technologies such as WPA and WPA2.
Support DHCP server/client.
Support multiple SSIDs (Up to 4, 2x SSIDs for 2.4G and 2x SSIDs for 5G).
Support VPN: WireGuard Client/Server, OpenVPN Client/Server.

Some application scenarios are listed as below.

A, Video monitor

B, Smart transportation

C, Public facilities

D, Industrial automation

E, Business networking




Technical Spec
Item
Description
Model
GL-X1200
CPU
Qualcomm QCA9563, @755MHZ
2.4G Wi-Fi Chipset
Qualcomm QCA9563
5.8G Wi-Fi Chipset
Qualcomm QCA9886
Memory/Storage
128MB DDR2 ; 16MB Nor-FLASH, 128MB NAND-FLASH (Optional)
3G/4G modem
Support 2x 4G LTE CAT4 (CAT6 is optional);
2x Standard SIM card slot, e-SIM is optional
4G Antenna
Maximum 4x external full-band antenna (700M ~ 2.7GHz)
Wi-Fi standard
Dual-frequency concurrent:
802.11b/g/n 2.4GHz,2x2; 802.11ac 5GHz,2x2
Wi-Fi Speed
Max.1167Mbps (2.4GHz 300Mbps, 5GHz 867Mbps)
Global Positioning System
GPS/Beidou (BDS) is optional, 1x external antenna for GPS
Watchdog
Built-in Watchdog chip
RTC
RTC Module included
Ethernet port
5x 10/100/1000Mbps Adaptive ethernet ports
(1x WAN + 4x LAN or 2x WAN + 3x LAN, software configurable)
Console
RS232 or RS485 serial port (RJ45 connector)
USB Port
1x USB2.0 Type-A
MicroSD
1x MicroSD (TF) Slot, support maximum 128GB
POE Output
1x PoE Output
Lightning Protection Class
6KV/1KV lightning protection for ethernet port (2 Wan)
(Common mode: 6KV, Differential mode: 1KV)
Enclosure
Metallic housing case with ground-screws
Temperature
Working Temperature: -20~70°C ;
Storage Temperature: -20~70°C
Our Company

GL.iNET Introduction

Shenzhen Guanglianzhitong Tech Co., Ltd.(GL.iNet) is a leading Wi-Fi router solution provider.
GL.iNet is founded in Shenzhen by an international team of experienced scientists and engineers in November, 2010.
Total staff more than 80 including with a R&D team of 30, a marketing and sales team of 15.
GL.iNet has own factory and HongKong office for design.
GLiNet supplies smart Wi-Fi routers and modules which is kernel parts of the smart home solution.
GLiNet provides OEM/ODM service and commercial solutions and technical support.
